Precision Analog & Data Converters
CSS designs precision analog and data-converter blocks for custom ASIC programs. Veteran CSS engineers support custom integrated circuits from analog front-end design through data-converter implementation.
Premier analog processing and data conversion
- Precision instrumentation and class AB amplifiers
- Voltage, current, transconductance, and transimpedance amplifiers
- Passive and active low-pass, high-pass, and bandpass filters
- Low-noise analog front-end and signal processing circuits
- 10-14 Bit SAR ADCs
- 4-8 Bit Flash ADCs
- 14-18 Bit Sigma-Delta ADCs and DACs
- 8-12 Bit resistive, capacitive, and hybrid Voltage DACs
- 10-12 Bit current mirror DACs
- Process selection is matched to the analog, data-converter, voltage, and lifecycle requirements of the ASIC program.
ASIC Design Expertise
CSS designs custom analog, mixed-signal, and data-converter IC blocks for application-specific integrated circuits. CSS’s veteran engineers average 25+ years of IC-design experience, supporting high-voltage, ultra-low-power, precision analog and data-converter, sensor and MEMS-interface, and wireless ASIC requirements.
IP Blocks
- 16-bit, 3rdOrder Sigma Delta ADC (16 MSPS core modulator with interpolation/decimation to 1MSPS; 200kHz signal BW)
- 14-bit SAR ADC (self-calibration, ULP, 100 kSPS, 0.1% INL, 2 LSB DNL)
- 10-bit SAR ADC with 22-channel Analog MUX
- 16-bit 3rdOrder Sigma Delta DAC (16 MSPS modulator, up to 2nd order interpolation from 1MSPS interface)
- 12-bit 4V DAC with 40V buffer (148 channels, <2us settling, 1 LSB INL)
- 0-2A, 10-bit DAC with ½ bit INL and ¼ bit DNL
- 8-bit offset adjust DAC
- 8GHz Receiver with low BW detector
- 8GHz Transmitter (output power settable range -30 to -10 dBm)
- 8GHz Transceiver with measured image rejection < -25dBm;
- Variable transconductance amplifier, Fin < 5 GHz
- Upconvert Mixer: RF 10-100GHz; IF 500MHz
- Frequency doubler, 5GHz <= Fin <= 20GHz
- 1 -> 8 Distribution Amp, 40GHz
- Clocked comparator, 20GHz clock
- Distributed LNA, 5GHz <+ Fin <= 45GHz
- DC to 30GHz regenerative divider
- Harmonic Mixer: Fin 46GHz, 10GHz <= Fref <= 22.6GHz
- Transmit Data Interface: 500MHz data, 1GHz clock
- 10-40GHz active balun
- 45GHz mmWave frontend
- Baseband convertor with 20 GHz clock
- Antenna reflectivity modulator
- RF power recovery unit for battery-free biomedical device
- Ultra-low power, 450kHz FM signal generator
- General Purpose Amplifiers
- Temperature range: -55C to +150C
- Supply range: 1.2V to 48V
- Bandwidth: 100KHz to 100MHz
- Open-loop gain: +65dB to +140db
- Class AB Output Amplifier (1kOhm & 50pF load)
- Rail-to-Rail Amplifiers
- Trans Impedance Amplifiers (TIA)
- 200 kHz signal BW and 70+dB SNDR
- Low Noise Amplifiers (LNA)
- High-Voltage Amplifiers
- Adjustable Gain Amplifiers (VGA & PGA)
- Rail-to-Rail, High-speed & Low-power Comparators
- Comparators with Hysteresis
- Latched Comparators
- 8-channel 100V Output driver for MEMS device
- Adjustable 70-100V Voltage Regulator
- 36V Switch Array for universal I/O device
- 16-32V LDO Regulator
- 100V Charge Pump (5V input supply)
- 1-wire multi-level HV power and communication interface (15V)
- 4-channel, 16-32V MEMS drivers
- +/- 18V 10-bit Current DAC
- 1A, 15V drivers for heating elements in thermal controller
- 45V drivers for piezoelectric transducers
- 18V transmit amps for 0-135kHz signal
- 0-40V DAC and Driver with 12-bit resolution
- 20V Charge Pump (1.3V input supply)
- 20V Antenna driver for wireless biometric device
- SPI, QSPI, I2C, & UART
- RS232 & RS485
- Single-Wire CAN (SAE J2411)
- Dual-Wire CAN (ISO 11898)
- K-line & L-line (ISO9141 & ISO14230)
- SAE J1850 & J1708
- ISO-Transport Layer (ISO 15765)
- SAE J1939
- Boost/Buck Switching Voltage Regulator
- Various LDOs (Plus, Minus, Fixed, Adjustable, etc.)
- Bandgap Voltage References
- Buffered & Unbuffered
- Chopper stabilized
- Trimmed & Untrimmed
- 25ppm – 100ppm/degC Tempco Stability
- Low Power (< 5uA)
- Compact (<50uA)
- PTAT Current References
- Integrated Current References
- +/-15% untrimmed
- +/- 1% trimmed
- Precision Current Reference (External resistor)
- 32kHz to 7MHz XTAL oscillators
- Example: 100kHz Crystal Oscillator (<1uA active current)
- Relaxation oscillators
- From 100kHz to 75MHz
- PLLs for clock multipliers
- Up to 500MHz outputs
- 555 Timer
- World’s lowest power 555 Timer(<5uA)
- Ultra-low-power custom SRAM bit cell and macro (<1K bit to >16K bit)
- Ultra-low voltage operation.
- Static current ~0uA
- Multiple process technologies
- Easy to reconfigure
- Ultra-low-power custom ROM bit cell and macro (<1K bit to >256K bit)
- Ultra-low voltage operation.
- Static current ~0uA
- Multiple process technologies
- Easy to reconfigure
